| GPU Engine Specs |
CUDA Cores: 4608 |
| Boost Clock (MHz) |
2602MHz |
| Base Clock (MHz) |
2325MHz |
| Thermal and Power Spec |
Minimum System Power Requirement: 650W |
| Supplementary Power Connectors |
1x PCIe 8-pin cables |
| Memory Specs |
Memory Clock: 28Gbps |
| Standard Memory Config |
16GB |
| Memory Interface |
GDDR7 |
| Memory Interface Width |
128-bit |
| Memory Bandwidth |
448 GB/sec |
| Feature Support |
Real-Time Ray Tracing: Yes |
| Ray Tracing Cores |
4th Generation, 72 TFLOPS |
| Tensor Cores |
5th Generation, 759 AI TOPS |
| NVIDIA Architecture |
Blackwell |
| Microsoft DirectX |
12 Ultimate |
| NVIDIA DLSS |
4 |
| NVIDIA Ansel |
Yes |
| NVIDIA FreeStyle |
Yes |
| Bus Support |
PCI Express Gen 5 |
| NVIDIA ShadowPlay |
Yes |
| OS Certification |
Windows 11 / 10, Linux, FreeBSDx86 |
| NVIDIA Highlights |
Yes |
| NVIDIA G-SYNC™-Ready |
Yes |
| Game Ready Drivers |
Yes |
| NVIDIA Studio Drivers |
Yes |
| NVIDIA GPU Boost™ |
Yes |
| Vulkan API |
1.4 |
| OpenGL |
4.6 |
| NVIDIA Encoder |
1x Ninth Generation |
| NVIDIA Decoder |
1x Sixth Generation |
| Graphics Card Dimensions |
Length: 300mm, Height: 116mm, Width: 41mm |
| Display Support |
Multi Monitor: up to 4 |
| Maximum Digital Resolution |
4K at 480Hz or 8K at 165Hz with DSC |
| HDCP |
2.3 |
| Standard Display Connectors |
3x DisplayPort 2.1b, 1x HDMI 2.1b |
